HL-ZX

HL series electric actuator is used to control 0 ~ 300. Rotating valves and other similar products, such as butterfly valves, ball valves, dampers, plug valves, louver valves, etc., it uses AC415V, 380V, 240V, 220V, 110V, DC12V, 24V, 220V AC power supply as the driving power source, with 4-20mA current The signal or 0-10V DC voltage signal is the control signal, which can move the valve to the desired position and realize its automatic control. The maximum output torque is 6000N-m, which can be widely used in petroleum, chemical, electric power, metallurgy, pharmaceutical, papermaking, Energy, water treatment, shipping, textile, food processing, building automation and other fields. At the same time, it has many advantages such as small size, light weight, beautiful appearance, unique structure, compact, rapid opening and closing, easy installation, small operating torque, convenient operation, digital display valve position, no maintenance and safe and convenient use.

  • Product Description
  • Features
  • Order consultation
  • Precautions
  • Certification
TOP

  Overview


HL series electric actuator is used to control 0 ~ 300. Rotating valves and other similar products, such as butterfly valves, ball valves, dampers, plug valves, louver valves, etc., it uses AC415V, 380V, 240V, 220V, 110V, DC12V, 24V, 220V AC power supply as the driving power source, with 4-20mA current The signal or 0-10V DC voltage signal is the control signal, which can move the valve to the desired position and realize its automatic control. The maximum output torque is 6000N-m, which can be widely used in petroleum, chemical, electric power, metallurgy, pharmaceutical, papermaking, Energy, water treatment, shipping, textile, food processing, building automation and other fields. At the same time, it has many advantages such as small size, light weight, beautiful appearance, unique structure, compact, rapid opening and closing, easy installation, small operating torque, convenient operation, digital display valve position, no maintenance and safe and convenient use.


  Features


Small and light, easy to disassemble and maintain, and can be installed at any position

Simple and compact structure, 90-turn quick opening and closing

Low operating torque, light and labor saving

Flow characteristics tend to be straight, good adjustment performance

Multiple control signals: switch control;

Proportional (adjustment) control: 0-10VDC or 4-20mA

Feedback output optional 4-20mA, auxiliary switch and feedback potentiometer (0~1K)

  Technical parameter


time

HL-ZX-01

Performance

Power

AC85~260V

AC24V

DC24V

DC12V

Time/torque optional

7S/6Nm9S/8.5Nm12Nm/13S

Rated current

0.2A

0.25A

0.25A

0.4A

Rotary angle

0~90°

Weight

0.5kg

Insulted resistance

100MΩ

installation angle

Any angle

Case material

Aluminium alloy die-casting

Position limiting

During electric operation; full open and close limit switch; during manual operation; mechanical stop

Enclosure protection

IP67

Surrounding temperature

-25~60

Product color

milk white (other colors customized)


  Dimensions




  Electrical principle
