  Technical Specification


Item

LQ1

LQ2

LQ3

LQ4

LQ4JS

-6

-10

-16

-20

-24

-35

-50

-80

-110

-200

-250

-400

-600

Output torque(N.m)

60

100

160

200

240

350

500

800

1100

2000

2500

4000

6000

Working time(S)

26

26

28

28

28

32

32

36

36

110

110

180

180

Motor consumption(W)

20

20

40

40

45

60

90

120

180

120

180

120

180

Rated current(A)

AC220V

0.45

0.5

0.6

0.6

0.7

0.9

1.3

1.5

2.2

1.5

2.2

1.5

2.2

AC110V

-

1.0

1.45

1.5

1.6

1.8

3.2

3.9

4.2

3.9

4.2

3.9

4.2

AV440V

-

0.26

0.30

0.35

0.39

0.42

0.86

1.2

1.6

1.2

1.6

1.2

1.6

AC415V

-

0.24

0.28

0.32

0.37

0.40

0.81

1.15

1.55

1.15

1.55

1.15

1.55

AC380V

-

0.22

0.25

0.3

0.35

0.38

0.8

1.1

1.5

1.1

1.5

1.1

1.5

AC/DC 24V

-

1.7

2.0

2.2

2.8

4.0

6.9

9.8

12.5

9.8

12.5

9.8

12.5

Handwheel turns

10

12

13

14.5

46

73

weight(Kg)

12

18

22

23

28

30

54

56

108

110

Remarks: All range actuators are dispatched with explosion proof plugs 2-NPT 3/4 fitted into the cable entries, it is the responsibility of the installer to ensure the appropriate cable adapters and packings with explosion proof.
